Topsky (LT-ZXD12)

A Topsky inspection robot that rides a hanging track through tunnels, pipe galleries and conveyor alleyways, watching equipment with thermal, visual, gas and acoustic sensing. It gives operators of confined and hazardous infrastructure a repeatable patrol, plus a remote eye they can steer whenever a reading needs a closer look.

In stock

BRAND:
TOPSKY
PART #:
LT-ZXD12
ORIGIN:
China
AVAILABILITY:
SUBJECT TO AVAILABILITY
SKU:
Topsky-LT-ZXD12

Topsky (LT-ZXD12)

A fixed camera watches one stretch of a tunnel without ever blinking, yet it cannot look round a corner. An engineer can walk the whole tunnel, but only once or twice a shift. Between those two extremes lies a gap that matters in every long, enclosed asset, and the Topsky (LT-ZXD12) is designed to fill it. It is a robot that rides a hanging track above the walkway and stops at the points that need attention. At each stop it brings thermal, optical, gas and acoustic sensing to bear, and it can be handed over to an operator whenever a reading deserves a closer look.

Robots Middle East sells the Topsky (LT-ZXD12) and supplies it to mining, utility, energy and infrastructure operators across the Middle East. Robots Middle East prepares each quotation, coordinates delivery to site and remains the point of contact for support once the system is installed. Buyers therefore deal with a single regional partner, from the first technical question to commissioning.

Background

Beijing Topsky Century Holding Co., Ltd.

The LT-ZXD12 is manufactured by Beijing Topsky Century Holding Co., Ltd., a Chinese company whose range spans several types of special-purpose robot for demanding industrial environments. This hanging-track inspection platform sits alongside the company's ground-based machines. Buyers comparing approaches can browse the wider Topsky range to see how the brand covers floor-level patrol, firefighting and other tasks. Within that family, the LT-ZXD12 is the option for sites where the route is fixed, long and enclosed.

The hanging-track principle

The robot's walking mechanism is a hanging track. The machine travels along a rail mounted overhead rather than driving on the floor. This has practical consequences in galleries and tunnels. Walkways stay clear for personnel and maintenance equipment, and the robot follows exactly the same path on every round. It also views equipment from a consistent height and angle, so images and temperature readings taken days apart can be compared like for like. The design copes with gradients up to a climbing angle of ≤40 °, which suits the inclines found in conveyor alleyways and sloping tunnel sections.

Technical Specifications

SpecificationValue
VersionLT-ZXD12 200W
Walking mechanismHanging track
Input/output voltage/powerAC127-220V/DC12V, 4A/200W
Flat endurance time5H
Charging time4H
Dimensions550mm in length × 260mm width × height 260mm
Body weight≤20kg
Climbing angle≤40 °
Storage temperature-40 ~ 85 ℃
Work humidity5-95%, no condensation
Camera30 times optical zoom, 5 million pixels
Infrared thermal imaging resolution384 × 288
SensorsInfrared thermal imaging sensors, gas sensors, audio sensors, 360-degree video instruments
Transmission protocolRS-485, RS-232, Ethernet, 4G, 5G, wireless wifi, electric line carrier, etc.
Smart preset pointsMaximum 300
Operating modesSwitches between automatic inspection and manual inspection
Explosion-proof certificationExplosion-proof Ben'an mobile inspection platform, coal security certificate number MAB170437

Specifications as published by the manufacturer; they are confirmed against the datasheet at quotation.

The manufacturer has not published the battery capacity, the battery type, the IP rating, the payload, the package contents or the operating system and software version; these are confirmed at quotation.

How does a hanging-track robot compare with fixed cameras and manual rounds?

Fixed cameras are dependable, but each one covers a single field of view. Covering a long gallery takes many units, plus the cabling and power to serve them. Manual rounds cover everything, but only at the moment the inspector passes. Readings also vary with the person, the lighting and the time available.

The LT-ZXD12 takes a middle course. A single robot carries one set of instruments along the whole route and stops at up to 300 smart preset points. At each point it records the same view, temperature profile, gas reading and sound. The camera combines 30 times optical zoom with 5 million pixels, so a gauge, a label or a cable termination can be framed from the track without moving the robot closer. The infrared thermal imager, with a resolution of 384 × 288, is suited to finding the hot spots that precede many electrical and mechanical failures. Gas and audio sensors add information that a camera alone cannot capture, such as an accumulating atmosphere or the change in sound of a failing roller.

Because the robot can switch between automatic inspection and manual inspection, it keeps the judgement of a trained operator. The routine patrol runs on its own. When something unusual appears, the operator takes control, steers the robot to the area and examines it in detail without anyone having to enter the space.

What should buyers know about power, connectivity and certification?

The robot accepts AC127-220V input and works at DC12V, 4A/200W. It offers a flat endurance time of 5H and a charging time of 4H. These two figures shape the patrol schedule, because they determine how long each circuit can last and how charging fits around it. Data can travel over RS-485, RS-232, Ethernet, 4G, 5G, wireless wifi or electric line carrier. That flexibility matters in underground sites, where the available network often depends on what was installed when the tunnel was built.

For coal mining and other hazardous settings, the platform carries the designation Explosion-proof Ben'an mobile inspection platform under coal security certificate number MAB170437. Buyers outside the issuing jurisdiction should check how this certificate relates to the hazardous-area rules that apply to their own site. Robots Middle East can include that question in the technical clarification that accompanies a quotation.

Who is the Topsky (LT-ZXD12) for?

The first group is operators of long, enclosed linear assets: mines with large conveyor alleyways, utilities running cable and comprehensive pipe galleries, and authorities managing high-speed tunnels. These buyers need consistent coverage of a fixed route and value an inspection record that can be compared over time.

The second group is facility owners responsible for underground plant rooms, such as water pump rooms and substations. Here the concern is often what happens between visits: equipment that warms up, leaks or changes sound when nobody is present. For these sites, a track-mounted robot offers routine presence without permanent staffing.

The third group is safety and asset-integrity teams who want to reduce how often people must enter hazardous or poorly ventilated spaces. The manual inspection mode lets them make a first assessment remotely before deciding whether to send a person in.

Not every site suits a fixed track. Open yards, changing layouts or areas without an overhead structure may call for a ground-based platform instead. For those cases, the UGVs category presents wheeled and tracked alternatives that Robots Middle East can quote alongside the LT-ZXD12.

What is the Topsky (LT-ZXD12) used for?

  1. Large conveyor alleyways: following the belt line to watch for overheating rollers, misalignment and spillage along its length.
  2. Underground water pump rooms: checking pumps, motors and pipework for heat, abnormal noise and gas build-up between staff visits.
  3. Underground substations: scanning switchgear and cable connections with thermal imaging to detect hot spots early.
  4. Urban comprehensive pipe galleries: patrolling shared utility corridors where water, power and communications services run side by side.
  5. Cable pipe galleries: tracking the temperature of cable runs and joints along routes too long to inspect closely on foot.
  6. High-speed tunnels: providing repeatable visual and environmental inspection of tunnel infrastructure from an overhead track.

Pricing and Availability

The Topsky (LT-ZXD12) is supplied on a project basis, so Robots Middle East provides pricing through a formal quotation rather than a fixed list. Each quotation reflects the route length, track installation, communication method and any site-specific requirements. Delivery, customs clearance and after-sales support are arranged together with the quotation. To begin, please share your site details and inspection objectives through the request form available on this page.

Frequently Asked Questions

Does the Topsky (LT-ZXD12) run on the floor or on a rail?

It uses a hanging-track walking mechanism, travelling along an overhead rail and leaving the walkway free for personnel.

Which sensors does the robot carry?

It is equipped with infrared thermal imaging sensors, gas sensors, audio sensors and 360-degree video instruments. The camera offers 30 times optical zoom with 5 million pixels.

How long can it operate between charges?

The flat endurance time is 5H and the charging time is 4H. Patrol schedules are planned around these two figures.

Can an operator take control during a patrol?

Yes. The product switches between automatic inspection and manual inspection, so an operator can steer it to examine an area in detail.

How does it send data back to the control room?

It supports RS-485, RS-232, Ethernet, 4G, 5G, wireless wifi and electric line carrier, among other transmission protocols.

Is the robot certified for coal mine use?

It is designated an Explosion-proof Ben'an mobile inspection platform under coal security certificate number MAB170437. Applicability to your own jurisdiction's hazardous-area rules should be confirmed during quotation.

Where can I buy the Topsky (LT-ZXD12) and what does it cost?

Robots Middle East supplies the Topsky (LT-ZXD12) across the Middle East. The cost depends on the route, installation and configuration, so it is set out in a tailored quotation requested through this page.

Summary

A fixed camera offers constancy without reach, and a manual round offers reach without constancy. The Topsky (LT-ZXD12) combines the two. It runs on a hanging track along the same overhead path, stops at up to 300 preset points, and records thermal, optical, gas and acoustic data that can be compared round after round. Its flexible connectivity and switchable automatic and manual modes fit it into the working life of conveyor alleyways, pump rooms, substations, pipe galleries and tunnels. Its coal security certificate also speaks to its intended place in hazardous underground work. For operators in the region who want a dependable presence along routes that people cannot watch continuously, a quotation from Robots Middle East on this page is the starting point.

Specifications

General

BRAND TOPSKY
PART # LT-ZXD12

What's included

Topsky LT-ZXD12 (LT-ZXD12)
