Topsky RXR-C11
Every ground penetrating radar scan records two things at once: what the antenna sees beneath the surface, and exactly where it was when it saw it. If either half slips, the radargram becomes harder to read and the defect harder to locate. The Topsky RXR-C11 brings both halves together on one platform. It is a lithium battery powered robot that carries ground penetrating radar and a distance measuring wheel, steered by wireless remote control across ground where a hand-pushed cart struggles to hold its line: broken carriageways, tunnel inverts, verges above municipal pipelines and the decks of bridges.
Robots Middle East sells the Topsky RXR-C11 to infrastructure owners, survey contractors and engineering consultancies across the Middle East. Our team prepares each quotation around the project in question, arranges delivery to the site or office the customer nominates, and provides support after handover, so that a single point of contact covers the robot from the first enquiry to its deployment in the field.
Background
Topsky and its ground robotics range
Topsky develops unmanned ground vehicles for demanding field work. Its catalogue includes specialised machines such as an explosion-proof firefighting and scouting robot, as well as wheeled robot chassis intended for integration projects. Within that family, the RXR-C11 is the platform dedicated to underground detection: rather than a general-purpose carrier, it is configured from the outset with ground penetrating radar and a distance measuring wheel. Readers comparing the wider line can browse the full Topsky range, or the broader selection of UGVs that Robots Middle East supplies.
A chassis built around independent wheels
The engineering of the RXR-C11 starts with its running gear. Each of the four wheels is driven independently, and the robot steers by four-wheel differential steering, varying wheel speeds rather than turning a steering axle. Front and rear double wishbone independent suspension lets each wheel follow the ground on its own, which helps keep the chassis, and the radar it carries, steady over uneven surfaces. The whole machine is protected to IP65 against dust and water, and the platform supports multiple antenna hosts with a quick switch between them, so a survey team can change the radar configuration to suit the task without rebuilding the robot.
Technical Specifications
| Specification | Value |
|---|---|
| Product type | All terrain ground penetrating radar robot, wireless remote control |
| Equipment fitted | Ground penetrating radar and distance measuring wheel |
| Antenna hosts | Supports multiple antenna hosts for quick switch |
| Drive | Four-wheel independent drive |
| Steering | Four-wheel differential steering |
| Suspension | Front and rear double wishbone independent suspension |
| Protection level | Robot machine protection level IP65 |
| Power | Electric, lithium battery |
| Supply voltage (DC) | 48V |
| Size | ≤ 1150mm in length, 930mm in width, 650mm in height |
| Weight | ≤ 115kg |
| Tire size | 13 * 5-6 |
| Tire style | Road tires (replaceable off-road tires, grass tires) |
| Maximum speed in a straight line | ≥ 1.4m/s, remotely controlled continuously variable transmission |
| Braking distance | ≤ 0.3m |
| Chassis height | 125mm |
| Climbing ability | ≥ 70% (or 35 °) (off-road tires) |
| Vertical obstacle crossing height | ≥ 120mm |
| Water wading depth | ≥ 250mm |
| Continuous walking time | ≥ 3h |
| Wireless remote control distance | ≥ 500m (open space) |
| Load capacity | Maximum load capacity of 30kg heavy object |
Specifications are as published by the manufacturer and are confirmed against the datasheet at quotation.
The manufacturer has not published the radar antenna frequency, the detection depth, the battery capacity, the operating temperature range, details of the remote controller, the radar software or the contents of the box; each of these is confirmed at quotation.
Why carry ground penetrating radar on a robot rather than a cart?
Ground penetrating radar is usually moved along a survey line by hand, which ties the quality of the data to the stamina and footing of the person doing the pushing. On a long tunnel section, a stretch of road under traffic management or a wet verge above a pipeline, keeping a steady pace and a straight line is genuinely difficult. The RXR-C11 moves that work onto a powered chassis with a remotely controlled continuously variable transmission, so the operator can choose a pace suited to the antenna and hold it, up to a straight-line maximum of at least 1.4m/s.
Position matters as much as pace. Because the distance measuring wheel travels with the radar on the same platform, the distance along the line is recorded by the robot itself rather than reconstructed afterwards. The operator, meanwhile, stays at a distance: the wireless remote control reaches at least 500m in open space, which keeps people away from traffic, unstable ground or confined spaces while the robot does the travelling. The manufacturer describes the RXR-C11 as replacing humans for efficient operations, and that is the core of its case: the person interprets the survey, the robot walks it.
Finally, the platform is not tied to a single antenna. Support for multiple antenna hosts with a quick switch means one robot can serve different survey tasks, which matters to contractors whose work moves between roads, bridges and tunnels from one week to the next.
How does the RXR-C11 handle rough and wet ground?
The answer lies in a combination of the figures above. With off-road tires fitted, the RXR-C11 has a climbing ability of at least 70% (or 35 °), and it crosses vertical obstacles of at least 120mm. A chassis height of 125mm gives clearance over debris and uneven surfaces, while the double wishbone suspension at both ends keeps all four wheels working. Road tires are standard on its 13 * 5-6 wheels, and they can be replaced with off-road or grass tires, so the same robot can be prepared for asphalt, loose ground or turf.
Water and dust are addressed directly as well. The robot wades through at least 250mm of water and carries IP65 protection, which suits drainage-affected tunnels, wet road works and the fine dust common on construction sites across the region. A braking distance of no more than 0.3m gives the operator precise control when working close to structures, and a continuous walking time of at least 3h on the 48V lithium battery system allows a substantial survey session between charges.
Who is the Topsky RXR-C11 for?
The RXR-C11 is aimed at organisations for whom underground detection is routine work rather than an occasional task. Municipal utilities and pipeline operators can use it to examine the ground above buried networks without sending staff along every route on foot. Road authorities and highway maintenance contractors gain a way to survey carriageways for defects while operators remain clear of live traffic. Bridge and tunnel owners, together with the engineering consultancies that inspect for them, will value a platform that keeps the radar steady on decks, linings and inverts.
Geotechnical and geological survey firms are a further natural fit, since the manufacturer names geological detection in complex underground engineering surveys among its uses. Contractors who need quality and defect checks on newly built works can also deploy it as part of handover inspections.
Buyers whose task is not radar detection, for instance those who need a firefighting platform or a bare chassis for their own payload, will find a better match elsewhere in the UGVs category, and Robots Middle East can advise on the most suitable model.
What is the Topsky RXR-C11 used for?
- Municipal pipeline surveys — detecting defects and disease conditions in the ground around buried pipeline networks.
- Road inspection — checking carriageways for quality problems and hidden defects while the operator stays clear of traffic.
- Bridge assessment — carrying the radar steadily across decks to look for defects within the structure.
- Tunnel inspection — surveying linings and inverts in tunnels where dust and standing water make manual work slow.
- Geological investigation — supporting geological detection in complex underground engineering surveys.
- Quality checks on new works — verifying construction quality before handover with repeatable, distance-referenced survey lines.
Pricing and Availability
Robots Middle East supplies the Topsky RXR-C11 on a quotation basis, as the final configuration, including the antenna host, the tire set and any accessories, depends on the work it will do. Delivery, customs clearance and after-sales support are arranged together with the quotation. A request for a quotation for the Topsky RXR-C11 is available on this page.
Frequently Asked Questions
How is the RXR-C11 controlled?
The robot and its equipment are operated through wireless remote control. The remote control distance is at least 500m in open space.
What detection equipment does the robot carry?
The RXR-C11 is equipped with ground penetrating radar and distance measuring wheel equipment. It supports multiple antenna hosts with a quick switch between them.
How deep can the radar detect?
Detection depth depends on the radar antenna fitted to the robot. Please describe the depths your survey needs to reach in your enquiry, and our team will advise on a suitable configuration.
Can the robot work in wet or dusty conditions?
Yes. The robot machine carries IP65 protection, and its water wading depth is at least 250mm.
How long does it run on one charge?
The continuous walking time is at least 3h. Power comes from a 48V lithium battery system.
Can the tires be changed for different ground?
Road tires are fitted as standard, and they can be replaced with off-road tires or grass tires. The climbing ability of at least 70% (or 35 °) applies with off-road tires.
Where can I buy the Topsky RXR-C11 and what does it cost?
You can buy it from Robots Middle East, which supplies it across the Middle East. The cost depends on the configuration, so please request a quotation and our team will prepare one for your project.
Summary
A radar survey is a record of what lies below and of where the antenna was at every moment, and the Topsky RXR-C11 is designed to keep both under control. Its independently driven, double wishbone chassis keeps the radar steady over rough, wet and dusty ground; its distance measuring wheel travels on the same platform as the antenna; and its wireless remote control keeps operators at a safe distance from traffic and difficult terrain. For utilities, road and tunnel authorities, bridge inspectors and survey firms in the region looking to move their ground penetrating radar work onto a robot, supplied, delivered and supported by Robots Middle East, this page is the starting point.
