SIASUN V-Groove Dual-Lift Conveyor Mobile Robot (V-Groove Dual-Lift Conveyor Mobile Robot)

Heavy materials in a battery plant seldom move one at a time, yet much of the equipment that carries them is built around a single load and a single destination. The SIASUN V-Groove Dual-Lift Conveyor Mobile Robot takes a different view of the problem. It treats the coil as a load to be carried in pairs, cradled rather than clamped, and delivered at conveyor height rather than at floor level. The result is a vehicle that behaves less like a forklift on autopilot and more like a moving section of the production line, one that can leave one station, travel a configured route and meet the next conveyor as though the two had been bolted together all along.

Robots Middle East sells and supplies the SIASUN V-Groove Dual-Lift Conveyor Mobile Robot to manufacturers and logistics operators across the Middle East. Robots Middle East prepares each quotation against the customer's layout and load requirements, arranges delivery to site and remains the point of contact for support once the robot is working on the production floor.

Background

SIASUN and its place in industrial automation

SIASUN is a Chinese robotics and automation company with its roots in the Shenyang Institute of Automation of the Chinese Academy of Sciences. Over the years it has built a broad portfolio that spans industrial robot arms, cleanroom handling equipment and a wide family of mobile robots for factory and warehouse logistics. Its mobile range runs from compact transport vehicles through to heavy-duty platforms intended for very large loads, and the V-Groove Dual-Lift Conveyor Mobile Robot sits within that family as a specialised machine for coil and pallet transfer. Buyers comparing the wider line-up can browse SIASUN's Mobile Robots on this store.

A conveyor platform rather than a tugger

The defining choice in this robot is what sits on top of the chassis. SIASUN builds it on an AGV/AMR chassis and integrates roller/chain conveying modules, so that the robot can dock accurately with floor conveyors and transfer material without an intermediate lifting step. Instead of a flat deck, the load is held on V-shaped arms. The dual-lift V-groove gives precise support for two coils and allows faster loading and unloading, while an electric screw mechanism sets the transfer height. Navigation relies on multi-sensor fusion, and docking accuracy is millimetre-level. A dispatching layer with configurable tasks and routes provides seamless connection between multiple stations, which is what allows a single vehicle to serve several points on a line.

Technical Specifications

Specifications are as published by the manufacturer and are confirmed against the datasheet at quotation.

SIASUN has not published the dimensions, travel speed, battery type and capacity, charging arrangement, safety sensors, coil size range, operating environment, a numerical positioning accuracy or the contents of the delivery; these are confirmed at quotation.

How does a V-groove dual-lift robot differ from a standard conveyor AGV?

A conventional conveyor AGV carries a flat-bottomed load, typically a pallet or tote, on a roller deck. That works well for square loads, but a coil is round, heavy and prone to shifting. The V-shaped arms of this SIASUN robot address the geometry directly: a coil rests in the groove, supported along its curvature rather than balanced on a flat surface. Because the V-groove is dual-lift, the robot provides precise support for two coils, which makes loading and unloading faster.

The second difference is height. Many lines feed coils at a working level well above the floor, and the electric screw lift covers a range from 1050 to 1850 mm. Combined with roller/chain conveying and millimetre-level docking, this means the robot can present its load at the level of the receiving conveyor and pass it across. The pallet capability remains, so the same vehicle can serve stations that handle palletised material alongside those that handle coils.

Which drive mode suits my facility?

SIASUN offers the robot with differential, steering-wheel or dual-steering drive. The choice is usually shaped by the layout. In general terms, differential drive suits routes where turning on the spot is useful, steering-wheel configurations suit longer, more open runs, and dual-steering arrangements are commonly chosen where a vehicle must manoeuvre with care in tight aisles or align precisely with fixed equipment. The vehicle weight spans 1500 to 2200 kg, and the configuration selected affects which figures apply, so Robots Middle East agrees the drive mode, the weight and the floor-loading implications with you when preparing the offer.

Who is the SIASUN V-Groove Dual-Lift Conveyor Mobile Robot for?

The clearest fit is lithium battery manufacturing. The robot supports full-process logistics in that industry, from electrode and cell production through to module and PACK stages, which makes it relevant to gigafactory projects and to established cell makers adding automation to existing halls. Electrode coil handling in particular benefits from a vehicle that cradles round loads and meets conveyors at height.

Beyond batteries, the combination of coil and pallet handling suits production logistics teams in other process-driven plants where heavy rolls or palletised goods move between fixed conveyor stations. System integrators building automated material flow will value the configurable dispatching and multi-station connection, since a single vehicle can be assigned to several transfer points.

Buyers whose loads are heavier than this robot's rated payload, or who move large assemblies rather than coils, may find a better match in SIASUN's heavy-duty platforms, such as the SIASUN 10,000 Kg Heavy-Duty Mobile Robot or the SIASUN 20T Heavy-Duty Mobile Robot (20T Heavy-Duty Mobile Robot). A broader view of automation for production halls is available under Factory Robots.

What is the SIASUN V-Groove Dual-Lift Conveyor Mobile Robot used for?

1. Electrode coil transfer: carrying electrode coils between coating, pressing and slitting stations in battery production.
2. Cell production logistics: moving material between cell production stages on configured routes.
3. Module and PACK supply: delivering palletised components to module and PACK assembly areas.
4. Conveyor-to-conveyor docking: passing loads directly from the robot's roller/chain modules to fixed floor conveyors.
5. Paired coil handling: transporting two coils at once in the dual-lift V-groove to shorten loading and unloading.
6. Multi-station circuits: serving several stations in sequence through configurable dispatching tasks.

Pricing and Availability

The SIASUN V-Groove Dual-Lift Conveyor Mobile Robot is supplied on quotation, because the drive mode, lifting configuration and integration with existing conveyors differ from one facility to the next. Robots Middle East reviews your load types, station heights and route layout and prepares an offer that reflects the configuration you actually need. Delivery, customs clearance and after-sales support are arranged together with the quotation. To begin, please send your requirements through the quotation request available on this page.

Frequently Asked Questions

What loads can the robot carry?

It is designed for heavy-duty pallet and coil handling, with a rated payload of ≤3000 kg. Coils are held on V-shaped arms, and the dual-lift V-groove supports two coils at once.

How high can it lift a load?

The electric screw lift covers a lifting height of 1050–1850 mm, which allows the robot to meet conveyors at different working levels.

How does the robot transfer material to a conveyor?

Roller/chain conveying modules on the robot dock accurately with floor conveyors, with millimetre-level docking accuracy.

Which drive modes are available?

SIASUN offers differential, steering-wheel and dual-steering drive. Robots Middle East will help you match the drive mode to your aisles and routes.

How is the robot navigated and dispatched?

Navigation uses multi-sensor fusion, and the dispatching system allows configurable tasks and routes with seamless connection between multiple stations.

What is the battery life and travel speed?

Battery type and capacity, the charging arrangement and the travel speed depend on the configuration. Robots Middle East provides these details together with your offer.

Where can I buy the SIASUN V-Groove Dual-Lift Conveyor Mobile Robot and what does it cost?

You can buy it from Robots Middle East, which supplies it across the Middle East. The cost depends on configuration and integration, so it is provided through a tailored quotation requested on this page.

Summary

Where most transport vehicles think in single loads at floor level, the SIASUN V-Groove Dual-Lift Conveyor Mobile Robot thinks in pairs and at conveyor height. Its V-shaped arms cradle two coils, its electric screw lift reaches from 1050 to 1850 mm, and its roller/chain modules dock with floor conveyors to millimetre-level accuracy, all on an AGV/AMR chassis rated for payloads of ≤3000 kg. For lithium battery plants moving material from electrode production to PACK, and for other facilities linking heavy-load stations, it offers a way to make transport part of the line rather than an interruption to it. For a configuration matched to your plant and a quotation from Robots Middle East, this page is the starting point.
